Type XR38
Description
The XR38 power entry module for circuit breakers with 3/8" thread neck combines up to 3 functions in one component: a C14 appliance inlet, a resettable overcurrent protection and a line filter. Appropriate line filters can be selected for the use in medical equipment applications according to IEC/EN60601-1.
You can choose between two standard versions: Standard version C with actuator guard (reset button protrudes from the module) and standard version D with actuator guard (reset button completely recessed). Thanks to screw mounting, the power entry module has a firm fit in the housing.
The power entry modules can be combined with 106, 1140, 2-5700, 1658 (only available in the USA) and 8330 circuit breakers.
Technical Data
| Voltage rating | AC 250 V |
|---|---|
| Current ratings | 10 A (IEC/EN) |
| Actuation | push button |
| Terminal design | blade terminals |
| Certificates | Appliance inlet: VDE/TÜV, CSA, UL |
Applications
- Commercial kitchen appliances
- Medical technology
Scopes of applications
- Laboratory equipment
- 3D printer
Downloads
- Data sheet 880.9 KB
- RMI CMRT1.5 MB
- Statement on per- and polyfluoroalkyl substances (PFAS)180.1 KB
- REACH264.1 KB
- RMI EMRT1.3 MB
- TSCA Letter of Confirmation244.1 KB
Power Entry Module Brochure
Systematically reducing of components is a major reason for a successful cost-saving design. And what is more: Less individual parts increases overall reliability and usually provides additional space. E-T-A’s power entry modules combine up to 5 functions in a single component: a C14/C20 appliance inlet, resettable overcurrent protection, an ON/OFF switch, a line filter and add-on modules for undervoltage release, remote trip or auxiliary contacts. Unlike conventional standard modules with fuses, E-T-A’s power entry modules are fitted with a conveniently resettable circuit breaker.
